H110S Single hinged watertight door
RAPP BOMEK H110S doors are designed and manufactured to meet the requirement in SOLAS 74 and IMO FTP code.
-
Threshold: Fixed, Removal or Flanged
Weight: 300 kg (Single leaf 900x2100)
-
Break-in resistance: Option RC4 break-in resistance
Noise reduction: 40dB, higher performance options
Air tightness: Option 0,5 m3/ m2h
-
Hinges: Each door leaf has 4 hinges with grease nipple fixed to the doorleaf with 3 screws and welded to the door frame. The hinges are special designed and are made of stainless steel AISI 316L.
Door handle: The Handle is of type Rapp Bomek HD-handle stainless steel quality AISI 316L.
Latch: the door is equipped with Rapp Bomek 4 points latch made of stainless steel AISI 316L, externally fitted to the door leaf.
Gasket: The fire gasket between door leaf and frame is made of special neoprene quality.
Door closer: Fire rated doors must be equipped with door closer, Rapp Bomek recommends DORMA TS 83 / EN7, adjustable.
-
window
kick-plate
padlock
doorstop
hold open
