H590 Single and double leaf higned door

Security

Jan 13

This product is very robust and meets high user safety requirements. Insulated door panel construction with hinges in stainless steel and security pins. H590D can be delivered in a variaty of sizes.

Sizes: Single max 1500x3900 (fire rated) Double max 3100x3900 (fire rated)
Threshold: Flat, Fixed, Removable or Drop-down
Material:
Carbon steel
Galvanized steel
Stainless steel AISI 304
Marine grade stainless steel AISI 316
Break-in resistance: RC5 or RC6 - EN1627
Fire rating: EI2120 – EN16034
Sound insulation: 39 dB, higher performance options
Air tightness: Level 3
Ballistic resistance: FB6 and FB7
Explosion resistance: Calculated dynamic load eq. EPR4
EMC: Advanced EMC Shielded Doors
The products can be manufactured in the desired dimensions and fitted with, or adapted for, special fittings related to evacuations, break-ins, access control, etc. This will entail restrictions in relation to the individual certificates.
Other Options
Panic bar, kick-plate, doorstop, Access control, bigger sizes available without fire rating
In accordance with NS EN ISO 9001
